Steam Boiler 40MT/Hr For Sugar Industry

ZG Series 40 t/h gas fuel steam boiler for sugar industry burns coke oven gas with natural circulation, outdoor furnishings, 7 degree design of seismic intensity. The overall layout of the ZG Series 40 t/h Gas Boiler is before the boiler rooms after the hanging, "π" type layout, water tube system, superheater which is all hanging on the roof of the boiler, economizers, air preheater is layouted on a steel frame.

40 MT/hr coke oven gas steam boiler
1 Rated evaporation：40t/h
2 Superheated steam pressure：3.82 MPa
3 Superheated steam temperature：450 ℃
4 Feed water temperature： 104℃
5 Exhaust gas temperature：130 ℃
6 Design thermal efficiency:  91%
7 Design fuel:  coke oven gas

Basic dimensions
1 Drum height：16400mm
2 Boiler width (left and right column centerline distance): 4810mm
3 boiler depth (Z1 tail of the column to the stud Center): 8940mm

For sugar mills, the coke oven gas fired boiler is efficient and energy saving. The various parts of the boiler heating surface has sufficient maintenance space between, which will help the boiler overhaul. The upper part of the boiler is anti-canopy, it can be arranged in the outdoor, which can save boiler room construction costs. ZBG, the China leading boiler supplier, is providing low price quality competitive gas fired boiler, coal fired boiler, oil fired boiler, biomass fired boiler, waste heat recovery boiler, as well as the pressure vessel autoclaves for clients!
